| Manufacturer AIDC | TSC |
|---|---|
| Model Name | Alpha-3R |
| Printer Type | Mobile |
TSC Alpha-3R Specs
Technical Information
- Maximum Mono Print Speed: 4.02 in/s
- Maximum Print Resolution: 230 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.83"
- Recommended Use: Label/Receipt Print
- Features:
- Lightweight
- Dust Resistant
- Water Resistant
- Barcode Symbology Supported:
- Code 39
- Code 93
- Code 128 UCC
- Code 128-A
- Code 128-B
- Code 128-C
- Codabar
- Interleaved 2 of 5
- EAN-8
- EAN-13
- EAN 128
- UPC-A
- UPC-E
- UPC-5 Digits Add-on
- UPC -2 Digits Add-on
- MSI
- Plessey
- POSTNET
- China Post
- GS1 DataBar
- PDF-417
- Maxi Code
- Data Matrix
- QR Code
- Aztec Code
General Information
- Product Type: Direct Thermal Printer
- Brand Name: TSC Auto ID
- Manufacturer: TSC Auto ID Technology Co., Ltd
- Product Model: Alpha-3R
- Product Name: ALPHA-3R - Portable Direct Thermal Printer
Physical Characteristics
- Height: 5.8"
- Width: 4.6"
- Depth: 2.8"
- Form Factor: Portable
- Weight (Approximate): 1.21 lb
Interfaces/Ports
- USB: Yes
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- RoHS
- WEEE
- Platform Supported: PC
- Package Contents:
- ALPHA-3R - Portable Direct Thermal Printer
- Windows Labeling Software CD Disk
- Quick Start Guide
- Belt Clip
- Li-Ion Battery
- Power Adapter
- ALPHA-3R - Portable Direct Thermal Printer
- Windows Labeling Software CD Disk
- Quick Start Guide
- Belt Clip
- Li-Ion Battery
- Power Adapter
- Certifications & Standards:
- IP54
- FCC
- CE
- CB
- CCC
- C-Tick
Media Types & Handling
- Maximum Label Width: 3.15"
- Media Type:
- Label
- Receipt
- Ticket
- Black Mark
- Media Thickness: 5.50 mil
- Media Sensor:
- Reflective Media Sensor
- Cover Open Sensor
- Label Core Size: 1"
- Maximum Roll Diameter: 2.24"
Battery Information
- Number of Batteries Supported: 2
- Battery Rechargeable: Yes
- Battery Run Time: 12 Hour
- Battery Chemistry: Lithium Ion (Li-Ion)
Fonts & Emulation
- Language Emulation:
- TSPL-EZ
- CPCL
Memory
- Standard Memory: 8 MB
- Memory Technology: SDRAM
- Flash Memory: 4 MB
Network & Communication
- Wireless LAN: Yes
- Wireless LAN Standard: IEEE 802.11b/g/n
Power Description
- Input Voltage: 7.4 V DC
- Power Source: Battery
Warranty
- Limited Warranty: 2 Year
