Wasp WPL305 Barcode Label Printer
Part #: 633808402006 | SKU: WAS21216

The WPL305 from Wasp is the latest in a line of high-quality desktop printers. The WPL305 creates barcode labels at a rate of 5 inches per second at 203dpi. It is extremely user friendly, with easy installation and media loading.

Wasp WPL305 Barcode Label Printer

Part Details: Desktop Barcode Label Printer, WPL305, Thermal Transfer, 5" Outer Diameter, 5 Inches per Second.
MSRP: $599.00 Price: $565.94
In Stock

Additional Information

Interface Options Parallel, Serial (RS-232), USB
Manufacturer Wasp
Max Roll Outer Diameter 5
Model Name WPL305
Print Resolution 203 dpi
Print Speed 5 ips
Printer Type Desktop

Technical Information

  • Maximum Mono Print Speed: 5 in/s
  • Maximum Print Resolution: 203 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.25"
  • Recommended Use: Label Print
  • Barcode Symbology Supported:
    • Code 39
    • Code 39C
    • Code 93
    • Code 128 UCC
    • Code 128-A
    • Code 128-B
    • Code 128-C
    • Code 11
    • Codabar
    • Interleaved 2 of 5
    • EAN-8
    • EAN-13
    • UPC-A
    • UPC-E
    • MSI
    • Plessey
    • POSTNET
    • PDF-417
    • Maxi Code
    • Data Matrix
    • Micro PDF-417

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Brand Name: Wasp
  • Manufacturer: Wasp Barcode Technologies
  • Product Model: WPL305
  • Product Name: WPL305 Thermal Label Printer

Physical Characteristics

  • Height: 7.4"
  • Width: 8.4"

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes
  • Parallel Port: Yes

Other

  • Platform Supported: PC
  • Certifications & Standards:
    • CE
    • FCC
    • TUV
    • UL
  • Additional Information:
    • Compact Design
    • Easy Media Supplies loading
    • One Indicator LED (Two Color)
    • WPL, ZPL emulation & EPL emulation
    • Font Rotations: 0, 90, 180, 270 degrees
    • Sensors:
    • Label Gap
    • Black Line
    • Head Open
    • Reflective (position adjustable)

Media Types & Handling

  • Maximum Label Width: 4.40"
  • Maximum Label Length: 39"
  • Media Type: Label
  • Media Size: Custom Size - 4.40"
  • Media Sensor: Reflective Media Sensor
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 5"

Fonts & Emulation

  • Language Emulation:
    • WPL
    • EPL
    • ZPL

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC

Memory

  • Standard Memory: 2 MB
  • Memory Technology: DRAM
  • Flash Memory: 1 MB

Warranty

  • Limited Warranty: 1 Year
Extended Details

Recommended Accessories for Model: Wasp WPL305 Barcode Label Printer

  • Wasp WPL608 Printhead Cleaner
    Part #: 633808441012 | SKU: WAS147748

    Cleaning Pen for All Thermal Printers
    Price: $17.27
    In Stock
  • Wasp 633808402082 Accessory
    Part #: 633808402082 | SKU: WAS211859

    WPL305 Peeloff W/Present Sensor
    MSRP: $49.00 Price: $47.73
  • Wasp 633808402105 Accessory
    Part #: 633808402105 | SKU: WAS211857

    WPL305 Cutter OptIon Full Cut
    MSRP: $199.00 Price: $193.83
  • Wasp 633808402068 Accessory
    Part #: 633808402068 | SKU: WAS147744

    KDU200 Stand-Alone Keyboard acts as a portable terminal input device for stand-alone printing applications. No external power supply is needed.
    MSRP: $199.00 Price: $193.83
  • Wasp WPL205 Printhead
    Part #: 633808402167 | SKU: WAS147745

    Replacement Printhead Kit, 203 dpi, Compatible Printer Model WPL205 & WPL305
    MSRP: $199.00 Price: $193.83

Recommended Labels for Model: Wasp WPL305 Barcode Label Printer

  • Wasp 633808402785 Barcode Label
    Part #: 633808402785 | SKU: WAS148075

    4" x 6" Direct thermal paper label. 4 roll case. Labels per Roll, 5" OD.
    MSRP: $82.00 Price: $77.48
    In Stock
  • Wasp 633808402761 Barcode Label
    Part #: 633808402761 | SKU: WAS144561

    4" x 2" Direct thermal paper label, 4 roll case, 1250 Labels per Roll, 5" OD.
    MSRP: $91.00 Price: $85.97
    In Stock
  • Wasp 633808402723 Barcode Label
    Part #: 633808402723 | SKU: WAS144560

    2.25" x 1.25" Direct thermal paper label, 4 roll case, 1900 Labels per Roll, 5" OD.
    MSRP: $65.00 Price: $61.42
    In Stock
  • Wasp 633808402587 Barcode Label
    Part #: 633808402587 | SKU: WAS148096

    4" x 6" Thermal transfer paper label. 4 roll case, 450 Labels per Roll, 5" OD.
    MSRP: $68.00 Price: $64.25
    In Stock
  • Wasp 633808402778 Barcode Label
    Part #: 633808402778 | SKU: WAS148074

    4" x 3" Direct thermal paper label. 4 roll case. 850 Labels per Roll, 5" OD.
    MSRP: $88.00 Price: $83.14
    In Stock

Recommended Ribbons for Model: Wasp WPL305 Barcode Label Printer

  • Wasp 633808431235 Ribbon
    Part #: 633808431235 | SKU: WAS38767

    WPL305/WPL608/WPL610 WXR 3.26" x 820' Resin Ribbon
    Price: $27.45
    In Stock
  • Wasp 633808431228 Ribbon
    Part #: 633808431228 | SKU: WAS38766

    WPL305/WPL608/WPL610 WXR 2.16" x 820' Resin Ribbon
    Price: $26.00
    In Stock
  • Wasp 633808431143 Ribbon
    Part #: 633808431143 | SKU: WAS38765

    WPL305/WPL608/WPL610 WWX 2.16" x 820' Wax Ribbon
    Price: $19.45
    In Stock
  • Wasp 633808431198 Ribbon
    Part #: 633808431198 | SKU: WAS148111

    WPL305/WPL608/WPL610 WPR 3.26" x 820' Wax-Resin Ribbon.
    Price: $20.91
    In Stock
  • Wasp 633808431204 Ribbon
    Part #: 633808431204 | SKU: WAS148112

    WPL305/WPL608/WPL610 WPR 4.33" x 820" Wax-Resin Ribbon.
    Price: $24.54
    In Stock

Recommended Warranties for Model: Wasp WPL305 Barcode Label Printer

  • Wasp WaspProtect Service Contract
    Part #: 633808600488 | SKU: WAS211889

    WaspProtect WPL305 1 Year Service Renewal
    Price: $129.74
    In Stock
  • BCI TrueSupport Basic Service Contract
    Part #: TRUESUPPORT-BAS-PRINT-1YR | SKU: BCI665134

    TrueSupport Basic Plan for Printers - 1 Year - Includes: Hardware Help Desk Support, RMA Triage, OEM Service contract mgmt.
    Price: $66.00
    In Stock
  • Wasp WaspProtect Service Contract
    Part #: 633808600136 | SKU: WAS147742

    WaspProtect Extended Service Plan for WPL305 Printer, 48 HR-2 Year
    MSRP: $89.00 Price: $84.09
    In Stock
