141890 Zebra

FX9500-41324D41-US - Zebra FX9500 RFID Reader

FX9500, RFID Reader, UHF, 4-Port, 128MB/128MB, GPIO, Ethernet, Linux Operating System, US Only. Antennae, Cables, Mounting Brackets, and Power Sold Separately.
Free Shipping


With exceptionally high RF sensitivity, the FX9500 delivers extremely high read performance, allowing longer read ranges for large distribution center and yard management applications, and higher throughput rates for high volume reading and densely packed goods situations. And, it's rugged, too, with IP53 sealing that can handle damp, or dusty work areas.
  • High-performance RFID reader
  • PXA270@624 MHz processor
  • 128Mb/128Mb memory
  • Ideal for high volume, high density, high throughput applications, and RF-challenging environments
  • Rugged design: IP53 sealing, diecast housing
  • Application flexibility and lower deployment costs
  • 4-port and 8-port reader configurations,
  • Small footprint

Additional Information

Port Capacity 4 Port
RAM Memory 128MB
Style Fixed
Operating System Linux
Frequency UHF
Antenna Capacity 4 Antenna
Interface Ethernet
Item Condition New
Manufacturer Zebra

General Information

  • Product Type: RFID Reader
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: FX9500
  • Product Name: FX9500 Fixed RFID Reader

Physical Characteristics

  • Height: 10.8"
  • Width: 7.3"
  • Depth: 2"
  • Material: Cast Aluminum
  • Weight (Approximate): 4.40 lb


  • Green Compliant: Yes
  • Green Compliance Certificate/Authority:
    • RoHS
    • WEEE
  • Additional Information:
    • 8-port reader configurations
    • PXA270@624 MHz processor
    • 128Mb/128Mb memory
    • 8-port reader configurations
    • UHF band, 902-928 MHz, 865-868 MHz
    • Web-based and remote firmware upgrade capabilities
    • External Interfaces: RS232 Serial Console - DB9, USB Client - USB Type B
    • Power Supply: +24v Vdc
    • Network Connectivity: 10/100 BaseT Ethernet - RJ45


  • Limited Warranty: 1 Year
