Additional Information
| Manufacturer AIDC | Metrologic |
|---|---|
| Model Name | MS5145 Eclipse |
| Scanner Capability | 1D |
| Scanner Type | CCD, Imager |
Metrologic MS5145 Eclipse Specs
Technical Information
- Scan Pattern: Single Line
- Connectivity Technology: Cable
- Light Source: Laser
- Image Sensor: CCD
- Barcode Symbology Supported:
- All Standard 1D Symbologies
- RSS-14
- RSS-Limited
- RSS-Expanded
- All Standard 1D Symbologies
- RSS-14
- RSS-Limited
- RSS-Expanded
- Maximum Scan Resolution: 4 mil
- Depth of Field:
- 0.38" - 1.50"@4.10 mil
- 0 mil - 2.63"@5.70 mil
- 0 mil - 4.13"@10.40 mil
- 0 mil - 5.63"@13 mil
- 0 mil - 7.13"@26 mil
General Information
- Product Type: Handheld Barcode Scanner
- Brand Name: Honeywell
- Manufacturer: Honeywell International, Inc
- Product Model: MS5145
- Product Name: Eclipse MS5145 Barcode Reader
- Product Line: Eclipse
Physical Characteristics
- Height: 1.4"
- Width: 2.5"
- Depth: 6.7"
- Color: Gray
- Weight (Approximate): 3.41 oz
Interfaces/Ports
- Host Interface: Keyboard Wedge
Other
- Certifications & Standards:
- Laser Class:
- IEC 60825-1:1993+A1:1997+A2:2001 Class 1
- EMC:
- FCC
- ICES-003 & EN55022 Class B
- Platform Supported: PC
- Additional Information: Keyboard Cable
Power Description
- Input Voltage: 5 V DC
