- A unique collapsible Ribbon hub that makes loading and unloading a snap
- Barcode Modulus: 5 mil to 110 mil
- Barcodes: Code 39, Interleaved 2 of 5, Code 128 (subsets A, B and C), Codabar, LOGMARS, UPC-A, UPC-E, UPC 2and5 digit addendums, EAN-8, EAN-13, EAN 2and5 digit addendums, UPC random weight, Code 93, MSI Plessey, Universal Shipping Container Symbology, UCC/EAN Code 128, Postnet, Code 128 MOD 43, PDF417, UPS MaxiCode (mode 2 and 3), DataMatrix, Telepen
- Cabinet: Metal construction
- Character Set Modified IBM Code Page 850, includes characters for English and most European, Scandinavian and Spanish speaking countries
- Color-Coded Operator Cues
- Easily accessible Printhead mechanism
- Easy to Maintain - Change the Printhead and the Platen Roller in less than 5 minutes
- Easy to upgrade and reconfigure for business growth
- Easy-to-Read front LCD Display
- Embossed media loading diagrams
- Font Expansion and Rotation: All Fonts are expandable vertically and horizontally up to 24x - Fonts and Graphics can be printed in four directions: 0-, 90-, 180- and 270-
- Graphics Support: .PCX,. BMP and .IMG files
- Interfaces: Centronics Parallel Port (IEEE 1284 compliant), RS-232 at 2,400 to 38,400 BPS, optional Ethernet
- Label Backfeed: For use with optional Cutter
- Media Sensing: Adjustable Sensor detects
- Media Type: Roll-fed or fan-fold materials, die-cut or continuous labels, perforated or continuous tag/ticket stock
- Media Window: Clear side door panel to easily monitor media supply levels
- Memory: 2MB Downloadable Flash Program Memory 16MB DRAM Memory
- Optional Ethernet and Twinax/Coax support allows the Printer to connect to virtually any host system environment.
- Power Source: Auto-sensing 115, 230 VAC 50/60 Hz, specify appropriate Power cord when ordering
- Powerful 32-bit multi-tasking Processor and an industry leading 16MB of addressable RAM
- Reverse Fields/Mirror Image: Any Font or Graphic Field can be printed as a normal or reverse image
- Standard Bi-Directional Parallel and High-Speed Serial Interfaces allow easy integration into your system.
- Windows Driver: Used for creating label formats using virtually any Windows-based program. Included on Datamax Accessories CD, or via our web site.
Choose the for your high-performance
printing needs
The is the fastest printer in the Datamax
I-Class series. The is an excellent
choice where high volumes of labels are required quickly, either on
demand or in batches. It is ideal for printing labels for
industrial, commercial, business and clinical labeling applications
The Features:
- Featuring a powerful 32-bit processor and an industry leading
16MB of addressable RAM, the provides
first label throughput at 6 ips, the fastest label in its
class.
- Easy to read front LCD panel display.
- Color-coded operator cues
- Embossed media loading diagrams
- Easily accessible printhead mechanism
- A unique collapsible ribbon hub that makes loading and
unloading a snap
- 3-Year Limited Warranty on Printer
- 1-Year (1 million inches) Printhead Warranty
Extended Details
